Thickness
(mm) |
1Mx2M |
3'
x 6'
(914 x 1829) |
4'
x 8'
(1219 x 2438) |
5'
x 10'
(1524 x 3048) |
0.3 |
4.76 |
3.98 |
7.07 |
11.05 |
0.4 |
6.34 |
5.30 |
9.43 |
14.73 |
0.5 |
7.93 |
6.63 |
11.78 |
18.42 |
0.6 |
9.51 |
7.95 |
14.14 |
22.10 |
0.7 |
11.10 |
9.28 |
16.50 |
25.79 |
0.8 |
12.69 |
10.61 |
18.85 |
29.47 |
0.9 |
14.27 |
11.93 |
21.21 |
33.15 |
1.0 |
15.86 |
13.26 |
23.57 |
36.84 |
1.2 |
19.03 |
15.91 |
28.28 |
44.21 |
1.4 |
22.20 |
18.56 |
32.99 |
51.57 |
1.5 |
23.79 |
19.89 |
35.35 |
55.25 |
1.6 |
25.38 |
21.21 |
37.71 |
58.94 |
1.8 |
28.55 |
23.86 |
42.42 |
66.30 |
2.0 |
31.72 |
26.51 |
47.13 |
73.67 |
2.3 |
36.48 |
30.49 |
54.20 |
84.72 |
2.5 |
39.65 |
33.14 |
58.92 |
92.09 |
3.0 |
47.58 |
39.77 |
70.70 |
110.51 |
3.2 |
50.75 |
42.42 |
75.41 |
117.88 |
4.0 |
63.44 |
53.03 |
92.27 |
147.34 |
4.5 |
71.37 |
59.66 |
106.05 |
165.76 |
5.0 |
79.30 |
66.29 |
117.84 |
184.18 |
5.5 |
87.23 |
72.91 |
129.62 |
202.62 |
6.0 |
95.16 |
79.54 |
141.40 |
221.02 |
7.0 |
111.02 |
92.80 |
165.00 |
258.30 |
8.0 |
126.88 |
106.05 |
188.54 |
294.69 |
9.0 |
142.74 |
119.31 |
212.11 |
331.52 |
10.0 |
158.60 |
132.57 |
235.67 |
368.36 |
12.0 |
190.32 |
159.08 |
282.80 |
442.03 |
16.0 |
253.76 |
212.11 |
377.07 |
589.38 |
19.0 |
301.34 |
251.88 |
447.77 |
699.88 |
22.0 |
348.92 |
291.65 |
518.47 |
810.39 |
25.0 |
369.50 |
331.42 |
589.18 |
920.90 |
|
|
SPECIFICATIONS : (Material 316) |
|
Thickness (mm) |
1Mx2M |
3'
x 6'
(914 x 1829) |
4'
x 8'
(1219 x 2438) |
5'
x 10'
(1524 x 3048) |
0.3 |
4.79 |
4.00 |
7.11 |
11.12 |
0.4 |
6.20 |
5.34 |
9.49 |
14.83 |
0.5 |
7.98 |
6.67 |
11.86 |
18.53 |
0.6 |
9.57 |
8.00 |
14.23 |
22.24 |
0.7 |
11.17 |
9.34 |
16.60 |
25.95 |
0.8 |
12.77 |
10.67 |
18.97 |
29.65 |
0.9 |
14.36 |
12.01 |
21.34 |
33.36 |
1.0 |
15.96 |
13.34 |
23.72 |
37.07 |
1.2 |
19.15 |
16.01 |
28.46 |
44.48 |
1.4 |
22.34 |
18.68 |
33.20 |
51.90 |
1.5 |
23.94 |
20.01 |
35.57 |
55.60 |
1.6 |
25.54 |
21.34 |
37.95 |
59.31 |
1.8 |
28.73 |
24.01 |
42.69 |
66.72 |
2.0 |
31.92 |
26.68 |
47.43 |
74.14 |
2.3 |
36.71 |
30.68 |
54.55 |
85.26 |
2.5 |
39.90 |
33.35 |
59.29 |
92.67 |
3.0 |
47.88 |
40.02 |
71.15 |
111.20 |
3.2 |
51.07 |
42.69 |
75.90 |
118.62 |
4.0 |
63.84 |
53.36 |
94.86 |
148.27 |
4.5 |
71.82 |
60.03 |
106.72 |
166.81 |
5.0 |
79.80 |
66.70 |
118.58 |
185.34 |
5.5 |
87.78 |
73.37 |
130.44 |
203.88 |
6.0 |
95.76 |
80.04 |
142.30 |
222.41 |
7.0 |
111.72 |
93.62 |
166.43 |
260.50 |
8.0 |
127.68 |
106.72 |
189.73 |
296.55 |
9.0 |
143.64 |
120.06 |
213.44 |
333.60 |
10.0 |
159.60 |
133.40 |
237.16 |
370.68 |
12.0 |
191.52 |
160.08 |
284.59 |
444.82 |
16.0 |
255.36 |
213.44 |
379.46 |
593.09 |
19.0 |
303.24 |
253.46 |
450.60 |
704.30 |
22.0 |
351.12 |
293.48 |
521.75 |
815.50 |
25.0 |
399.00 |
333.50 |
592.90 |
926.71 |
|
|
RemarksĄG |
(1) Stainless Steel Sheet Weight Measurement :
Base
Weight x Thickness (m/m) x Width (m/m) x Length
(m/m) |
|
(2) Stainless Steel Pipe Weight Measurement :
(Outer
Diameter-Thickness) (m/m) x Thickness (m/m) x
0.025 = Weight (1M) |
|
